Rockwell Automation 45LFM Label Photoelectric Sensor User Manual
Page 4
4
Dimensions—mm (inches)
24.1
(0.95)
20.3
(0.8)
140 (5.5)
25.4 (1.0)
5.1
(0.2)
7.6 (0.3)
15.2 (0.6)
Gap 0.76 (0.03)
(Adjustable)
31.8
(1.25)
M4 x 0.7
(x4)
30.5 (1.2)
15.2
(0.6)
SENSOR
Output Polarity and Signal Waveforms
Output
Output Polarity
NPN
Ground
NPN
+Vin
PNP
Ground
PNP
+Vin
OFF
SINK
OFF
SINK
SOURCE
OFF
SOURCE
OFF
Publication 75009–234–01(B)
May 2004
Printed in USA
PHOTOSWITCH
R
is a registered trademark of
Rockwell Automation.
