Pub. no. - date – Rockwell Automation 20P PowerFlex DC Drive - Frame A Field Circuit Fuse Replacement User Manual
Page 2
Publication 20P-IN038A-EN-P - March 2009
Copyright © 2009 Rockwell Automation. All rights reserved. Printed in USA.
www.rockwellautomation.com
Americas: Rockwell Automation, 1201 South Second Street, Milwaukee, WI 53204-2496 USA, Tel: (1) 414.382.2000, Fax: (1) 414.382.4444
Europe/Middle East/Africa: Rockwell Automation SA/NV, Vorstlaan/Boulevard du Souverain 36, 1170 Brussels, Belgium, Tel: (32) 2 663 0600, Fax: (32) 2 663 0640
Asia Pacific: Rockwell Automation, Level 14, Core F, Cyberport 3, 100 Cyberport Road, Hong Kong, Tel: (852) 2887 4788, Fax: (852) 2508 1846
Power, Control and Information Solutions
1S7A27
2. On the bottom of the drive, remove a fuse by inserting a screwdriver in
the slot on the top of the fuse holder, carefully pushing in toward the
drive and turning the fuse counterclockwise. When the fuse holder
releases, remove the holder and fuse.
3. Insert the new fuses into the holders and replace the fuse holder caps.
Field circuit fuses
Bottom View of Drives
Drive with Fan at Bottom
Drive with no Fan at Bottom
