Installation Instructions
PowerFlex
®
DC Drive - Frame B Bimetal
Thermostat
What This Kit Includes
•
Bimetal thermostat
•
Wire leads with connector
•
Thermal grease
•
Static strap
Tools That You Need
•
Phillips
®
screwdriver
•
Flathead screwdriver
•
Nut driver or wrench
•
Torque wrench
Phillips
®
is a registered trademark of Phillips Screw Company.
ATTENTION: Only qualified personnel familiar with DC
drives and associated machinery should plan or implement the
installation, start-up and subsequent maintenance of the system.
Failure to comply may result in personal injury and/or equipment
damage.
ATTENTION: To avoid an electric shock hazard, ensure that
all power to the drive has been removed before performing the
following.
ATTENTION: This drive contains ESD (Electrostatic
Discharge) sensitive parts and assemblies. Static control
precautions are required when installing, testing, servicing or
repairing this assembly. Component damage may result if ESD
control procedures are not followed. If you are not familiar with
static control procedures, reference A-B publication 8000-4.5.2,
“Guarding Against Electrostatic Damage” or any other
applicable ESD protection handbook.
Document Outline
- Front Cover
- What This Kit Includes
- Tools That You Need
- What You Need to Do
- Step 1: Remove Power from the Drive
- Step 2: Remove the Protective Covers and Power Wiring
- Step 3: Remove the Pulse Transformer and Switching Power Supply Boards
- Step 4: Remove the Existing Bimetal Thermostat
- Step 5: Install the New Bimetal Thermostat
- Step 6: Install the Pulse Transformer Board and Switching Power Supply Board
- Step 7: Replace the Protective Covers and Documenting the Change
- Related Documentation
