Rockwell Automation 20P PowerFlex DC Drive Communication Interface Cable User Manual
Page 3
PowerFlex® DC Drive Communication Interface Cable
3
3. Remove the top protective cover from the drive:
a. For frame A drives, press in on the sides at the bottom edge of the
cover and at the same time pull the cover toward you to pull it
partially off the drive chassis. Next, at the top of the drive, pull the
cover forward, away from the drive, until the pins fit in the keyhole in
the top of the cover, then carefully lift the cover off of the drive
chassis.
Important: The HIM assembly is connected via the Communication
Interface cable to the Control board and therefore will not
pull free from the drive until disconnected. See
instructions.
Frame A
When metal pin fits in keyhole,
lift cover off drive chassis.
