Installation Instructions
Embedded EtherNet/IP Option Card for
DriveLogix
™
5730 Controllers
What This Kit Contains Verify that your kit contains the items listed in the following table. If your
kit does not contain the correct items, contact your Allen-Bradley sales
representative.
Tools That You Need
• Phillips ®
screwdriver for M3 screws
• Standard (flat blade) screwdriver
Phillips
®
is a registered trademark of Phillips Screw Company
!
ATTENTION: To avoid an electric shock hazard, verify that the
voltage on the bus capacitors has discharged before performing
any work on the drive. Measure the DC bus voltage at the +DC &
–DC terminals of the Power Terminal Block (DC+ & DC- in high
power drives). The voltage must be zero.
!
ATTENTION: HOT surfaces can cause severe burns. Do not
touch the heatsink surface during operation of the drive. After
disconnecting power allow time for cooling.
!
ATTENTION: This drive contains ESD (Electrostatic
Discharge) sensitive parts and assemblies. Static control
precautions are required when installing, testing, servicing or
repairing this assembly. Component damage may result if ESD
control procedures are not followed. If you are not familiar with
static control procedures, reference A-B publication 8000-4.5.2,
“Guarding Against Electrostatic Damage” or any other
applicable ESD protection handbook.
Quantity: Description
1 Embedded EtherNet/IP Option circuit board
2 Screws
2 Stand-offs
