Rockwell Automation 20P PowerFlex DC Drive - Frame D Overvoltage Clipping Board Fuse Replacement User Manual
Page 3
3
5. Remove the three fuses at locations F11, F21 and F31.
6. Install the new fuses.
7. Close the control panel. See steps
and
on
.
8. Replace the DPI cable (if present).
XCD
X1UVW1
XUVW
F31
F21
F11
