Weidmuller PRO-H Series Power Supplies User Manual
Page 12
Tel: (800) 849-9343
Fax: (804) 379-2593
www.weidmuller.com
Date:
28 September
2009
Issue: 1.0
Page
12
1
2
3
1
2
3
1 2 3
4
J1
J2
J5
1 2 3 4 5 6 7
1 2 3
J1
J2
1
2
3
1
2
3
1 2 3
4
J3
J4
J1
J2
J5
1
2
3
2 1
Connectors of CP T SNT 360W 24V 15A & CP T SNT 360W 48V 7.5A with Output Voltage adjustment
Connectors of CP T SNT 600W 24V 25A & CP T SNT 600W 48V 12.5A with Output Voltage adjustment
J1
J2
J3
J4
Pin 1
Earth
GND (-)
S+
Normal mode
Pin 2
Neutral
GND (-)
S-
Common
Pin 3
Live
Vout (+)
-
Parallel mode
Pin 4
-
Vout (+)
-
-
Pin 5
-
DC-OK Signal
-
-
Pin 6
-
DC-OK Relay contact 1
-
-
Pin 7
-
DC-OK Relay contact 2
-
-
J1
J2
J3
J4
J5
Pin 1
Earth
GND (-)
S+
Normal mode
DC-OK Relay contact 1
Pin 2
Neutral
GND (-)
S-
Common
DC-OK Relay contact 2
Pin 3
Live
Vout (+)
-
Parallel mode
DC-OK Signal
Pin 4
-
Vout (+)
-
-
-
2
3
1
2
1
J3
J4
Fig.: 5.3
Fig.: 5.4
