1. WALL MOUNT
BRACKET ASSEMBLY
9. HANDLE ASSEMBLY
12. DOOR THRESHOLD
16. STRUCTURAL RAIL
3. ROLLERS
20. GLASS SUPPORT 19. DOOR SEAL STRIP
7. DOOR
23. PHILLIPS SCREW 2"
3
MODEL VG06051
6. SIDE GLASS PANEL
5. SMALL FRONT FIXED
PANEL 2. FIXED PANEL HOLDER
4. BIG FRONT FIXED
PANEL
8. CORNER BRACKET
10. FIXED PANEL
BOTTOM CLIP
11. BOTTOM DOOR GUIDE 15. DOOR STOPPER
17. STRUCTURAL RAIL
SCREW
18. SIDE SEAL STRIP
98010
21. PHILLIPS SCREW
1 1/8"
22. HEX SCREW 1 5/8"
98018 98019 98020 97022-48
97022-60 97021
97019 97020-48
97020-60 98027 98021
98028
98029 95008-48
95008-60 98024
98030-48
98030-60
98031
96013
13. LEFT END CUPS 14. RIGHT END CUPS
24. PLASTIC ANCHORS
98060 98061
98001
98035 98039 98036 98038
PLASTIC ANCHOR 25.
98037
HEX SCREW COVER 26.
96040
