Vigo VG06051 User Manual
Page 2
MODEL VG06051
NOTE: INSTALLATION MUST BE DONE BY A QUALIFIED, LICENSED PROFESSIONAL.
GLASS THICKNESS 3/8"
PLEASE READ INSTRUCTIONS BEFORE PROCEEDING
OWNER'S MANUAL
INSTALLATION INSTRUCTIONS FOR SHOWER ENCLOSURE
2
Packing List
1.
Wall mount bracket (1pc)
2.
Fixed panel holders (2pc)
3.
Rollers (4pc)
4.
Big front fixed panel (1pc)
5.
Small front fixed panel (1pc)
6.
Side glass panel (1pc)
7.
Door (1pc)
8.
Corner bracket (2pc)
9.
Handle assembly (1pc)
10.
Fixed panel bottom clip (1 pc)
11.
Bottom door guide (1 pc)
12.
Door threshold (1pc)
13.
Left threshold end cup (1pc)
14.
Right threshold end cup (1pc)
15.
Door stopper (2pc)
16.
Structural rail (1pc)
17.
Structural rail screw (1pc)
18.
Side seal strip (3pc)
19.
Door seal strip (3pc + 1 extra)
20.
Glass support (2pc)
21.
Phillips screws 1 1/8" (3pc)
22.
Hex screws 1 5/8" (2pc)
23.
Phillips screws 2" (1pc)
24.
Plastic anchors white (3pc)
25.
Plastic anchors green (3pc)
26.
Hex screw cover (8pc)
12
23
15
16
2
3
9
7
17
19
6
18
10
11
1
4
8
24
15
18
20
22
18
21
13
14
25
5
19
