03-000049 rev A Vicor 800-735-6200 Westcor Division 408-522-5280 Applications Engineering 800-927-9474 Pg. 9
10-32 OUTPUT STUDS
TRIM
3
SxJ2 REMOTE SENSE/TRIM
PIN CONNECTOR
1
2
- SENSE
+ SENSE
MATING CONNECTOR:
HOUSING: MOLEX (50-57-9403),
TERMINAL FEM CRIMP 24-30 AWG: MOLEX (16-02-0103)
USE CRIMP TOOL: MOLEX (11-01-0208)
A. OUTPUT STUDS - SINGLE, DUAL OUTPUTS - when populated with full or half size module(s)
-V OUT
+V OUT
2
3
4
5
6
7
8
10
11
12
13
14
15
16
1 9
MATING CONNECTOR:
16 PIN HOUSING: MOLEX (39-01-2160)
TERMINAL FEM CRIMP 18-24 AWG: MOLEX (39-00-0039)
USE CRIMP TOOL: MOLEX (11-01-0197)
9 +V OUT M3
10 -V OUT M3
11 N/C
12 +V OUT M2
13 -V OUT M2
14 TRIM M1
15 +V OUT M1
16 -V OUT M1 1 +V OUT M3
2 -V OUT M3
3 TRIM M3
4 +V OUT M2
5 -V OUT M2
6 TRIM M2
7 +V OUT M1
8 -V OUT M1
*SxJ1 (16 PIN OUTPUT, REMOTE SENSE
AND TRIM PIN CONNECTOR)
PIN DESCRIPTION PIN DESCRIPTION
B. 16 PIN MOLEX CONNECTOR - SINGLE, DUAL, TRIPLE OUTPUTS - when populated with
quarter size modules
PFC MicroS Design Guide
Output Connections for the PFC MicroS
OPTIONAL CONNECTOR KIT FOR PFC MICROS (PART# 19-130044. Available for purchase from Westcor)
