Spot-Lite Users Guide
Curing
Once the unit is warmed up the timer has been set curing can commence. The end(s) of the
wand(s) should be held or fixed close to the working area.
For maximum cure speed, the tip of the wand should be within 5mm of the material to be cured.
The Spot-Lite can now be activated by either pressing down the GREEN button located on the front
panel or by depressing (and then releasing) the foot switch. The shutter will open and the time will
commence its cycle. You will note that the timer counts down to zero at which point the shutter is
closed, the GREEN indicator light goes off and the RED Indicator light is reilluminated. (Note: if
necessary the shutter can be closed by pressing the shutter close button on the front panel of the
machine).
Note. The temperature on the top surface of the Spot-Lite unit may exceed 55 degrees Cen-
tigrade.
