Bush Hog
®
TOUGH
4215 Series Rotary Cutters
BUSH HOG ® TOUGH FeaTUReS
TOUGH 10 Gauge Deck Construction
TOUGH 7 Gauge Steel Strongbacks
TOUGH
1/4 Inch Sidebands
TOUGH Spring Shock absorbers On each axle arm
TOUGH Heavy Duty axles
TOUGH Powder Coat Paint
SPECIFICATIONS SUBJECT TO CHANGE WITHOUT NOTICE Page 28
MODel 4215
Cutting Width 15 ft
Cutting Capacity 2 inch Diameter
Dimensions (width x length) 15 ft 7 inches x 12 ft 2 inches
Transport Width 15 ft 7 inches
Type Hitch 3 Point Cat. II & III Standard & Quick Hitch
Cutting Height 2 to 16 inches
Deck Thickness 10 gauge
Side Bands 1/4 x 10 inches
Minimum Tractor HP 125 PTO
Driveline ASAE Cat. 5, for 1000 PTO speed tractors only
Cross Shaft Slipclutch
Gearbox HP (3) 160 - Center, 110 - Outboard
Tractor PTO Speed 1000 RPM
Driveline Protection (3) 2 Plate Slip Clutch
Height adjustment Choice of Manual Height Bundle or Hydraulic
Blade Holders Round or Straight
Blades 1/2 x 4 inches - Uplift
Blade Tip Speed 17,280 FPM (Center), 15,708 FPM (Outboard)
Tires Laminated
axles Single Tires Only
Deflectors Front Belting and Rear Band
approximate Weight (Pull with Single Axle) 3911 lbs
Highway lighting Standard
Options Single Tailwheel for Lift, Grass Baffle Kit, Shredding Kit 30/38/40 inch Rows
Warranty 1 year limited warranty with a 1 year gearbox limited warranty
