Bush hog, Tough, 2012 series rotary cutters

Bush Hog
®
TOUGH
2012 Series Rotary Cutters
BUSH HOG
®
TOUGH FeaTUReS
TOUGH 10 Gauge Deck Construction
TOUGH 5 Year Gearbox Limited Warranty
TOUGH 7 Gauge Sidebands
TOUGH Replaceable Wide Skids
TOUGH Cushioned axle arms
TOUGH Powder Coat Paint
SPECIFICATIONS SUBJECT TO CHANGE WITHOUT NOTICE
Page 21
MODeL
2012
Cutting Width
11 ft 9 inches
Dimensions (width x length)
12 ft 2 inches x 10 ft (Lift), 12 ft 2 inches x 13 ft 4 inches (Pull)
Type Hitch
3 Point Cat. II & III Standard & Quick Hitch, Center Pull Self Leveling or Semi-Mount, Cat.II & III
Cutting Capacity
2 inches
Cutting Height
2 to 12 inches
Deck Thickness
10 gauge
Side Bands
7 gauge /10 inches deep
Minimum Tractor HP
60 PTO (Pull), 70 PTO (Lift)
Driveline
ASAE Category 4
Cross Shaft
Rubber Element
Gearbox HP
120 Main and 90 Outboard
Tractor PTO Speed
540/1000 RPM
Driveline Protection
4 Plate PTO Slip Clutch
Height adjustment
Choice of Manual Height Bundle or Hydraulic Cylinder
Blade Holder(s)
Round Pans
Blades
1/2
x 4 inches - Corner Uplift
Blade Tip Speed
15,490 FPM/540 RPM; 15,422 FPM/1000 RPM
Tires
Laminated Tire on Lift and Semi-Mount Models, Laminated Tire or 15 inch Automotive Wheel on Pull Models, Used Aircraft Tire on Pull Type Only
axles
Adjustable Axle Arms for Row Spacing, Choice of Single or Dual Axles on Pull Models
Deflectors
Front Belting and Rear Bands (Chains Optional)
Safety Tow Chain
Standard for Pull Models
approximate Weight
2184 lbs (Lift), 2267 lbs (Pull), 2079 lbs (Semi-Mount)
Options
Single Row Chain Deflector Front and Rear
Warranty
1 year limited warranty with a 5 year gearbox limited warranty
FeaTUReS
• Sloped Deck • High blade tip speeds • Deep sidebands • Quick detach gearbox shields
