Bush hog, Tough, 2720 flex wing rotary cutters

Bush Hog
®
TOUGH
2720 Flex Wing Rotary Cutters
Recommended Tractor HP Minimum 90 PTO
BUsH HOG
®
TOUGH FeaTURes
TOUGH 10 Gauge steel Deck
TOUGH 7 Gauge strongbacks
TOUGH
1/4
Inch sidebands
TOUGH Heavy Duty Wheel Hubs and axle spindles
TOUGH Independent spring Cushion On each axle arm
TOUGH Heavy Duty axle With Turnbuckles
TOUGH Greaseable axle Pivot Points
TOUGH Driveline safety Retaining Rings
TOUGH 5 Year Gearbox Limited Warranty
TOUGH Powder Coat Paint
SPECIFICATIONS SUBJECT TO CHANGE WITHOUT NOTICE
Page 33
• Perma-Level® Hitch• High blade tip speeds • Deep sidebands • Heavy duty wheel hubs • Quick detach gearbox shields
MODeL
2720
Cutting Width
20 ft
Cutting Capacity
2
1/2
inch Diameter
Cutting Height
2 to 14 inches
Overall Width x Length (from clevis to wheel hub at transport height)
21 ft x 15 ft 11 inches
Transport Width (outside wing skid to outside wing skid)
11 ft
Tractor PTO
540 RPM/1000 RPM
Minimum Tractor HP
90 PTO
Deck Thickness
10 gauge
side Bands
1/4
x 10
1/2
inches
Gearbox HP
235 - Transfer, 190 - Center, 190 - Wings
PTO Drivelines
Input: Constant Velocity or Cardan/jackshaft - Cat. 5 (540 RPM), Cat. 4 or 5 (1000 RPM)
Wing Drivelines
ASAE Cat. 5
slip Clutches
(3) 4 - Friction Plates
Blade Tip speed
16,328 FPM/540 RPM; 16,000 FPM/1000 RPM
Blades
1/2
x 4 inch Uplift with 6 inch Overlap
Type Hitch
Self Leveling with Perma-Level® Hitch, or Available with 2
5/16
inch Ball Hitch
Wing Flex
87° Up to 22° Down
Tires
Laminated Tire, Used Aircraft Tire, Foam Filled Used Aircraft Tire, Pneumatic 15 inch Wheel (tire not included),
15 inch x 6 inch Wheel for 9.5L x 15 inch Tire, Modified Laminated Tire with 10 Bolts
axles
Dual or Tandem Walking Axles for Center Section; Single Axle, Dual Axle or Tandem Walking Axle for Wings
Wheel shock Protection
Independent Spring Shock Absorption on Each Axle Arm
Deflectors
Standard Front Belting, Rear Metal Band
Options
Chain Shielding, Valve Stand Kit, Grass Baffle Kit, Deck Rings, Straight Blade Bar, Shredder Kit
Warranty
1 year limited warranty with a 5 year gearbox limited warranty
FeaTURes
FeaTURes
BUsH HOG eXCLUsIVe:
Driveline safety retaining rings
