Bush Hog 3710 User Manual
Bush hog, Tough, Single wing flex series

Bush Hog
®
TOUGH
3710
Single Wing
Flex Series
Rotary Cutters
Recommended Tractor HP Minimum 80 PTO
BUSH HOG
®
TOUGH FeaTUReS
TOUGH 7 Gauge Deck Construction
TOUGH 7 Gauge Strongbacks
TOUGH
1/4
Inch Sidebands
TOUGH Independent Spring Cushion at each axle arm
TOUGH Heavy Duty axle Turn Buckles
TOUGH Greaseable axle Pivot Points
TOUGH Heavy Duty Wheel Hubs and axle Spindles
TOUGH Driveline Safety Retaining Rings
TOUGH 5 Year Gearbox Limited Warranty
TOUGH Powder Coat Paint
Model 3710
• Perma Level Hitch • Cylinder style anti wrap device around lower gearbox housing
• High blade tip speeds • Deep sidebands • Heavy duty wheel hubs • Quick detach gearbox shields
SPECIFICATIONS SUBJECT TO CHANGE WITHOUT NOTICE
Page 31
MODeL
3710
Cutting Width
10 ft 6 inches
Cutting Capacity
3
1/2
inch diameter
Cutting Height
2 to 14 inches
Overall Width x Length (from clevis to wheel hub at transport height)
11 ft 8 inches x 14 ft 6 inches
Transport Width (from weight box to wing skid)
8 ft
Tractor PTO
540 RPM/1000 RPM
Minimum Tractor HP
80 PTO
Deck Thickness
7 gauge
Side Bands
1/4
x 10
1/2
inches
Gearbox HP
235/Transfer, 190/Center & Wing
PTO Driveline
Input: Constant Velocity or Cardan/jackshaft - Cat. 5 (540 RPM)
Cat. 4 or 5 (1000 RPM)
Wing Driveline
ASAE Cat. 5
Slip Clutches
(2) 4 Friction Plates
Blade Tip Speed
16,289 FPM/540 RPM; 16,000 FPM/1000 RPM
Blades
1/2
x 4 inches – Uplift with 6 inch Overlap
Type Hitch
Self Leveling with Perma Level Hitch® or 2
5/16
inch Ball Hitch or Swivel Clevis Hitch
Wing Flex
87° Up to 22° Down
Tires
Laminated, Pneumatic or Aircraft
axles
Greaseable with bushings
Wheel Shock Protection
Independent Springs/Each Axle
Deflectors
Standard Front Belting and Rear Band, Optional Chains Front and Rear
Options
Chain Shielding, Tandem Walking Axle, Deck Rings
Warranty
1 year limited warranty with a 5 year gearbox limited warranty
FeaTUReS
BUSH HOG exCLUSIve:
Driveline safety retaining rings
