Bush Hog TOUGH SM60 - Manual

Bush Hog
®
TOUGH
Side Mount Rotary Cutters
BUSH HOG ® TOUGH FeaTUReS
TOUGH 10 Gauge Deck and Sidebands
TOUGH anti-Cavitation Protection
TOUGH Cast Iron Pump
TOUGH Round Bladeholder
TOUGH Hydraulic Relief Valves Provide
Overload Protection
TOUGH Powder Coat Paint
SPECIFICATIONS SUBJECT TO CHANGE WITHOUT NOTICE Page 19
MODel SM60
Cutting Width 5 ft
Cutting Capacity 1 inch
Dimensions (transport width x length) 10 ft 5 inches x 5 ft
Minimum Tractor Weight 6000 lbs
Minimum Tractor lift Capacity 3200 lbs (at 24 inches behind lift pins)
Type Hitch Category II Standard, Cat. II & III Quick Hitch
Deck Thickness 10 gauge
Tractor PTO Speed 540/1000 RPM
Blade Holder Round
Type Blades 1/2 x 3 inches, Double Edge
Blade Tip Speed 17,300 FPM at 540 RPM
Blade RPM 1100
Blade Rotation Clockwise, but Reversible
Cutter Head Movement 90° Up to 85° Down
Driveline ASAE Category 4, 540 or 1000 RPM
Hydraulic Pump Mounting Machine Only, PTO Driven
Hydraulic Oil Capacity 35 Gallons, Factory Filled
Hydraulic Capacity 24 GPM
Overload Protection Hydraulic Relief Valve
Counterweight 275 lbs Standard
Max. extension of Cutterhead 145 inches from Tractor Centerline
extension arm Travel 31 1/4 inches
approximate Weight 1675 lbs
Deflectors Standard Equipment
Options Side Gauge Wheel with Laminated or Solid Tire, Tailwheel Assembly for Mainframe with Laminated Tire, Valve Stand, Chain Shielding
Warranty 1 year limited warranty
