CCTV Tester User’s Manual





2.4 Specification

Model

CT330(S) CCTV Tester

Video Test

Signal Mode

NTSC/PAL automatically suitable

Display

inch LCD screen, 960 x 240 resolution 3.0

Video Input

1 channel BNC

Video Output

1 channel BNC

Adjustable

Brightness adjustable

PTZ Control

and Test

Communication

RS232, RS422 simplex and RS485

Protocol

Include more than 20 kinds of protocols or customized

Baud Rate

2400,4800,9600,19200

Multimeter

Function

DC Voltage Test

Max: 1000V, Precision: 0.1mV

AC Voltage Test

Max: 750V, Precision: 0.1mV

Resistance Test

Max: 40MΩ, Precision: 0.1Ω

Power to

Camera

Voltage

DC12V

Working Time

45 hours to normal camera

Max Current

400mA

Other

Functions

Video analyzing

Video signal attenuation analyzing

UTP Cable Test

Test UTP cable connection state

Signal Generating

Output 1 channel video signal for testing monitor

RS485 Data Test

Test the RS485 data sent from controlling device

OSD Menu

English OSD menu

Keyboard

New design with number buttons, easy to operation

Power and

Battery

Power Adapter

DC5V

Battery

3000mAh rechargeable battery inside

Rechargeable

6 hours recharging time

Low Consumption

Sleeping mode, display battery power state

Working Time

10 hours

Others

Work Temperature

-22°F–+158°F (-30°C–+70°C)

Work Humidity

30%90%

Dimension

6.54" x 3.58" x 1.89" (166mm x 91mm x 48mm)

Weight

.75lb (340g)
