H.264 Network DVR
- 11 -
8CH
GND
GROUND
NET
INTERNET INTERFACE
AOUT
Audio output
NCX,NO
X
Alarm Out
USB
with USB Mouse, USB Disk
VIN-IN Video input
ALARM
1,2,3,4
Alarm in
MOUSE
with USB Mouse
AIN-IN Audio input
RS-485
RS-485
VGA
Video output
V-OUT Video output with BNC interface
