Regency ® L234 Direct Vent Gas Insert
37
MAINTENANCE
11) Unplug the fan connector wires.
12) Remove the 2 screws that hold the fan bracket
in place.
13) Remove the fan by sliding the fan forward
and lift up and out.
14) Remove the ground screw which holds the
ground wire.
Ground Wire
15) Replace the fan.
NOTE: Bend the connector clips down before
re-installing the fan cover plate.
Connector Clips
16) Reverse steps 14 - 1.
10) Remove the fan cover plate by undoing the
12 screws that hold it in place.
Fan Cover Plate Removed
