Regency ® L234 Direct Vent Gas Insert
19
INSTALLATION
SCREEN DOOR INSTALL/ REMOVAL GLASS DOOR INSTALL/ REMOVAL
1) Remove the glass door.
a) Pull off the left side spring hook that holds the door in place. While
holding the hook turn it upside down and place it into the middle opening
on the top side mounting bracket. Repeat for right side
.
b) Swing the door out 45 degrees and lift up and out.
1) Remove the glass door.
2) Hook the screen door over top of the glass door.
Spring Hook
Screen Door
Spring Hook
Top Mounting Bracket
2) To install the door - reverse steps.
3) Install the screen door and glass door as one unit.
Glass Door
Spring Hook
Top Mounting Bracket
Spring Hook
