Page 19
Operating the machine
19
Fig. 6: Mounting the dividing head
•
Put the dividing head (B) on the shaft (MN) as shown in the illustration.
•
Put the dividing head hopper (A) onto the axle (DA).
Fig. 7: Locking disk on the driver and dividing head viewed from below
Make sure that one of the four grooves (NT) engages with the locking disk (RS).
Pos : 7. 13 /00005 Ü berschrif ten/ 1. 1 Ü bersc hrift en/ 1. 1 Übersc hrift en BD A/ 11 Pr obengef äß eins et zen @ 3\ mod_1302780091987_9.doc @ 25081 @ 2 @ 1
5.6 Inserting sample vessel
Pos : 7. 14 /00004 Warnhinweis e/ V0062 VOR SICHT Gl ass plitt er @ 3\ mod_1302690193882_9. doc @ 24640 @ @ 1
A
B
MN
RS
DA
NT
B
(from
below/inside)
