Cleaning and service
36

Turning the studs (U) in a clockwise direction pushes the cutting bar closer
to the rotor knife and reduces the cutting gap accordingly. Turning in an anti-
clockwise direction increases the cutting gap.

Tighten the (WS) screw and check the cutting gap. Repeat the procedure if
necessary.

Tighten the (W) screw at 7Nm again after adjusting the cutting bar.

Then mount the right and left covers onto the device again.
NOTE
Do not set the cutting gap at less than 0.3 mm. Contact between the cutting plates
and the cutting bars can damage mechanical components.
The tightening torque for the (W) screw must be 7Nm. It is not otherwise possible
to guarantee that the cutting bars will be positioned securely.
