5.2 Overview table of the parts of the device
Pos : 8. 6 / 00010 Bedienungsanlei tungen Kapit elsamml ung en/SM 200/ 0015 SM200 Bedienung/ 1570 SM 200 Modul Tabelle der G erät et eile @ 3\ mod_1280230790859_9. doc @ 22160 @ @ 1
Element Description Function
A Feed hopper access barrier Prevents people reaching into the feed hopper
B Plunger When pulled, it releases the material feed chute.
Pushes sample onto the rotor.
C Metering plunger Pushes the material to be ground into the feed hopper
area of the filling plunger
–
Pulled out: the material can be fed.
–
Pushed in: the material remains in the area of
the filling plunger.
D Detent pin Prevents the filling plunger being pulled out, blocks it or
releases it.
–
Pulled out: allows the filling plunger to move
freely
–
Released: filling plunger latches in the top
position
E Mini detent pin Locks the door latch
F Handle for door latch Allows the door to be opened
G Control panel Starting and stopping the device, setting the speed
H Parallel section rotor Size reduction tool
I Bottom sieve
The size and type of its perforation influences the
fineness of the material being comminuted
J Ring filter Air outlet and sieve for sample material
K Collecting receptacle Collects comminuted stock
L ON/OFF switch (main switch) Connecting and disconnecting the device to/from the
power grid.
- ON = LED (red) STOP lights up
- OFF = all LEDs are off
M Connection cable Power connection
O Rotor shaft Accommodates the size reduction tool
P Cutting bars Counterpart for the size reduction tool
R Feed hopper For feeding the sample material
S Fastening screws for feed hopper Locking screws for the feed hopper
T Grinding chamber door Closes the grinding chamber
