Please read the following notes before installing
Electrical shock from voltages used in this system can cause injury or death. Prior to making any
electrical connections, or performing maintenance and repair, ensure power is removed.
Mains electrical connections should be made only by qualified personel in accordance with local
regulation.
Safety goggles should be worn while using power tools.
Step 1: Carefully mark out the mounting holes for the keypad and the hole of the cable feed.
Step 2: Drill the marked holes for the mounting points and the cable feed. When drilling the holes, ensure
that you are aware of any hidden cables or pipes. Once the holes have been drilled, fit the supplied wall
plugs and feed the cable through the cable feed hole before securing the reader to the wall using the
screws supplied.
Step 3: Fit the keypad to the mounting plate and secure using the screw provided.
Fitting the keypad
