Paxton Switch2 control unit - Manual (Page 3)

Page 3
X
Single or multiple
codes
Silent operation
20 wrong keystrokes
= 60 second lockout
Door open time
(seconds)
Change
Programming Code
Exit button
Set a
user code
Data Reset (except
Programming code)
OR One code only Multiple codes allowed
Silent Beep on
OFF ON
Enter time in seconds
(default = 07, max = 60)
Open door for
time in option 5
Toggle door open
until pressed again or
toggle code entered
Enter user code
4-8 digits
Re-enter
user code
Enter 6 digit
Programming Code
= Delete
= Normal
= Toggle
= Duress
Enter 6 digit
Programming Code
Re-enter 6 digit
Programming Code
6
OR
OR
X
OR
2
4
6
8
OR
OR
OR
2
2
2
2
2
3
4
7
5
6
9
8
6
6
START - Enter the 6 digit Programming Code and hold down a function key
for 3 seconds. - The unit beeps and the LED flashes faster.
Continue the key sequence to set the option - The keypad returns to operating mode.
Function keys
= Hold down for 3 secs
4
1 Combined Card &
Keypad modes
Section 3 - CARDLOCK/PROXIMITY with TOUCHLOCK mode
(i) The KP reader must first be initialised in TOUCHLOCK mode: See Section 2
(Individual Toggle function is not available)
(ii) Set up the required operating mode, as follows:
(iii) Present enrolment card
Card plus PIN. A card requires a 4 digit PIN to be assigned to it before it will work, as follows:
Present
enrolment
card
Present user
card
Enter PIN Re-Enter PIN
Card plus Code.
Access is granted by presenting a valid token and then entering a valid user code.
Card or Code. Access is granted by presenting a valid token or entering a valid user code.
Touchlock programming - Function 2 to enable multiple user codes, Function 8 to add user codes. (4 digits)
1
Card plus PIN Card or Code Card plus Code
2 3 OR OR Enter 6 digit
Programming
Code
Hold for 3 secs
1
PR OX IM IT Y
en ro lm en t c ar d
1. A t installation, p
resent thi s
card to th
e reader to
validat e
the tok
ens in this p
ack.
2. T o re- va lidate a user tok
en,
presen t this enrolment
card
to the reader follo
wed b y the
user tok en. 1. At in sta llat ion , p res en t th is c ard to th e
rea de r to va lida te th e t ok en s in th is p ack
2. To re -va lida te a us er to ken pr ese nt th is
en rolm en t c ard to th e r ea der fo llow ed by th e
use r to ken
Pa xto n A cce ss
FUNCTION CARD en rolm en t c ard
Mo re i nfo : htt p:/ /pa xto n.i nfo /74
Amber and
Green flash
LED's flash faster Amber flashes
See Section 3
9
