The first time the system is powered up the control unit will beep 3 times a second.
This indicates the unit needs programming. There are 3 programming options:
Using tokens only (CARDLOCK or PROXIMITY) see Section 1
Using codes only (TOUCHLOCK) see Section 2
Using tokens and PIN/codes (CARDLOCK/PROXIMITY with TOUCHLOCK) see Section 3
FACTORY RESET
1. Disconnect power
2. Disconnect GREEN and MAUVE wires
3. Insert link wire between GREEN and MAUVE terminals
4. Reconnect power - unit will beep 4 times
5. Disconnect power
6. Remove link wire
7. Reconnect GREEN and MAUVE wires
8. Reconnect power - unit will beep 3 times a second
9. Proceed with Initialising a new system
INITIALISING A NEW SYSTEM
This box can be used to write down the Programming Code for future reference.
Ensure that this information is stored in a secure place.
The reader's default indication has all the LED's on. Access granted is denoted
with a single flashing Green LED. Access Denied is a single flashing Red LED.
Section 2 - TOUCHLOCK
Choose a 6 digit Programming Code and load this into the unit as follows:
DO NOT USE 123456 - The default User Code (1234) will open the
door before the Programming Code had been fully entered.
6 digit Programming
Code
The default user code is now set to 1234
Section 1 - CARDLOCK or PROXIMITY
Enrolling a card pack.
All tokens will now be validated.
Tokens can now be issued to users
Present/swipe enrolment card
To bar a user:
The user card is now barred
Present/swipe user's shadow card
6 digit Programming
Code
Adding an additional Proximity card pack.
You need to be in possession of a
valid enrolment card for this system. Present this enrolment card to the reader and the Amber
LED will flash with the Green & Red LED's off. Present the Enrolment card from the new card
pack. The reader will beep and all LED's will be lit. The additional cards will now be valid. Repeat
this with each reader and with any additional card packs. Any valid enrolment card can be used
to add further packs. If an incorrect enrolment card is used to start the process, the Red LED will
be lit and the reader will produce a squeak sound as it rejects the card.
You can now set up the user codes and features using the programming chart.
Example: - Setting a user code to unlock the door under Normal conditions.
Enter user code
4-8 digits
Re-enter
user code
4 8
Enter 6 digit
Programming
Code
Hold for 3 secs Normal
A user can be re-validated by showing the enrolment card
followed by the user card or re-entered if used in Card+PIN mode.
PR OX IM IT Y
en ro lm en t c ar d
1. A t installation, present thi
s
car d to th
e reader to
validat
e
the t
ok ens in thi
s pack.
2. T o re- va lidate a us
er tok
en,
presen
t this enrolment card
to the reader
follo wed b y the
user to
ken.
1. At in sta llat ion , p res en t th is c ard to th e
rea de r to va lida te th e t ok en s in th is p ack
2. To re -va lida te a us er tok en pr ese nt th is
en rolm en t c ard to th e r ea der fo llow ed by th e
use r to ken
Pa xto n A cce ss
FUNCTION CA
RD
en rolm
en t c ard
Mo re i nfo : htt p:/ /pa xto n.i nfo /74
