Paxton OEM Reader keypad kit User Manual
Paxton For Home
Page 1
Ins-30042 - OEM Reader keypad kit
Suitability
Fitting
Exit button
(push to make)
0V
Black
9-15V DC
Whit
e
Grey
12V DC release current rating
must be less than 1A.
*
(fuse rating 1A)
* The diode current rating must be
equal to or greater than the current
required to drive the release.
14/11/2011
Security-sensitive doors
Wet environments
Mounted on metal surface
Readers mounted together
between readers
300mm
User cards are NOT supplied with this unit. Please supply your own user cards.
+
-
+12V DC
