4 Page
Reader 1: Settings for Reader 1 and Keypad 1 on the ACU.
Reader 2: Settings for Reader 2 and Keypad 2 on the ACU.
Alarm: Contains settings for the different types of alarm.
Codes: Valid codes can be viewed, added and removed.
(Can only be viewed when a keypad is active).
Events: Shows the events for the control unit selected.
Name: Each reader can be named individually if required.
Reader type: Set the reader type, if applicable.
Keypad type: Set the keypad type, if applicable.
Token data format: Select the data type being used on
the system. (New formats can be created).
Reader operating mode: Set the operating mode.
Timed operating modes: A different operating
mode can be configured within a time window.
Reader action: Set the action required when
access is granted.
Software installation
11V DC 15V DC
110 mA 350 mA
24V DC
4 A
1 A
500 mA
0 °C + 55 °C
200
200
2
2
2
1
10,000
10,000
50
250
64
2,454
103 mm 118 mm 23 mm
Voltage
Relay switchable current
Relay switchable voltage
Operating temperature - Battery limits
Electrical
Environment
Dimensions
PCB Current (depending on activity)
Features
Waterproof
Min
Width Height
Max
Min Max
Depth
Min Max
Number of PIN's
Access Levels
Time Zones
Alarm output current
Maximum door open time
Doors per ACU
Reader ports per ACU
Readers per port
Keypads per port
ACU per data line
Data lines per PC
Data retention after total power loss
Events stored in ACU with no server connection
Number of Cards
Number of Codes
Specifications
Door name: Name the ACU.
Door open time: Set the door open time.
Unlock the Door during: Permanently unlocks the door
while this timezone is active. - Should be set to 'At No Time'
for normal user operation.
No
Combined reader port output current
9 hours
1 sec 999,999 sec
