To delete a card pack
Factory reset
1. Power down the unit.
2. Press and hold down the exit button.
3. Power up the unit. After 3 seconds the Red LED will come on and the unit beeps.
4. The unit will then reset and all the LED's will come on.
5. Release the exit button.
User cards are NOT supplied with this unit. Please supply your own user cards.
Compatible with any Track 2 ISO magstripe card
Voltage
Maximum load output current
Reader head life
-20 °C +55 °C
IPX7
1,000,000
11V DC 14V DC
90 mA 110 mA
1 A
300 Oe 4000 Oe Lo-Co & Hi-Co
1000
4 x 250
34 mm 89 mm 34 mm
Specifications
Electrical
Environment
Dimensions
Min Max
Width Height Depth
Current
Operating temperature
Cable length
Reader
IP Rating
Outdoor use
Swipes
Number of Cards
Number of Card Packs
Magnetic stripe coercivity
1. Card packs may be deleted from the system if required. Once a card pack has been deleted another one may
be enrolled in its place.
2. To delete a card pack, take the master card and swipe it backwards through the reader.
3. Swipe the master card backwards again and the reader LED's will go out. After 5 seconds the reader will beep
and the LED's will come back on.
4. The card pack will now have been removed from the system.
3 metres
Min Max
