Paxton 2A/12V DC boxed power supply with Net2 ACU - Manual (Page 3)

13V DC 13.8V DC
2 A
1 A
100V AC 240V AC +/- 10%
1.2 A
50 Hz 60 Hz +/- 3 Hz
0 °C +45 °C
232mm 320mm 80mm
236mm 320mm 80mm
150mm 100mm 62mm
Status Lights
Specifications
Operating temperature - Battery limits
PSU Electrical
Output voltage
Maximum load output current
Maximum battery charging current
Mains supply voltage
Mains supply current
Mains supply frequency
Features
Statement of Conformity
The declaration of conformity is available on request. Contact details are provided at: http://paxton.info/596
Green
Red
Battery backup
Fast/Trickle charge
Deep discharge protection
Mains failure alarm (PSU)
Tamper alarm
This LED is on when the input supply has failed - Power is being supplied by the battery.
This LED is on when the input supply is healthy.
The cabinet can accommodate a 12V / 7Ah battery.
The battery is continuously charged to keep it at maximum capacity.
If battery voltage falls below 9.5V, it will automatically disconnect - Red LED goes out.
Registers an alarm if the mains power fails when connected to an ACU or I/O board.
Registers an alarm if the lid is opened when connected to an ACU or I/O board.
Environment
Metal Cabinet
Plastic Cabinet
Battery Compartment (Plastic Housing)
Dimensions
: The following warnings and instructions MUST be adhered to. Read the instructions before installing and powering the
equipment. Keep the instructions in a safe place for future reference.
: RECEIVING INSPECTION- Remove any traces of packing material from the unit as such debris may create a fire or shock hazard.
Unpack the unit with care and inspect for transit damage. If damage is suspected, the unit must not be used or tested, but should be
returned to Paxton for investigation and the damage reported to the carrier.
: INSTALLATION- Only qualified and trained personnel, familiar with this type of product and who fully understand these instructions
should install, connect or test this equipment. There are no user serviceable parts within the PSU unit.
: - The equipment is intended for indoor use only in dry locations. This is a Class A product. In a domestic environment this product may
cause radio interference in which case the user may be required to take adequate measures.
: - The installation must meet National Wiring Regulations and IEC60950-1 standards.
: - Disconnect Devices: A readily accessible disconnect device shall be incorporated in the building wiring to include an appropriately rated
circuit breaker to disconnect both poles with at least a 3.0 mm contact gap. After switch off, all internal capacitors will discharge to safe
levels within 60 seconds under normal conditions. Under fault conditions, charge may be held for much longer and suitable precautions
should be taken before handling the unit.
: - Protection device: The fusing characteristics of the protection device to be used are T3.15AH250V
WARNINGS
Min Max
Width Height Depth
Waterproof No
ACU Electrical
Min Max
See accompanying documentation ( ins-30000 - Net2 classic, ins-30075 - Net2 nano, ins-30080 - Net2 plus )
SAFETY WARNING
RISK OF EXPLOSION IF BATTERY IS REPLACED BY AN INCORRECT TYPE.
DISPOSE OF USED BATTERIES ACCORDING TO THE INSTRUCTIONS.
