Paxton PROXIMITY P200 & P200E metal mount reader User Manual
Paxton

Suitability
Fitting
Mounted on metal surface
Security-sensitive doors
Wet environments
Readers mounted together
P200
P200E metal mount
between readers
500 mm
between readers
500 mm
Reader covers
The P200 comes supplied with Black and White covers. The P200E is only available in Black.
Overview
The P200 is a standard P series reader with a much larger coil to give an increased read range with hands free
tokens. This larger coil makes it unsuitable for mounting the reader directly onto metal surfaces, posts, etc as
the radio field becomes distorted and so the P200E (External) has been designed with the reader coil spaced
away from the backplate.
The read range of both units is similar to the standard P series reader with passive tokens but is greatly
extended (up to 2.5 metres) when used in conjunction with a hands free interface, tokens and keycards.
P200
P200E
Cable extensions
Readers can be extended using Belden CR9540 10-core overall screened cable to a maximum of 100 metres.
15/03/2011
Ins-30026 PROXIMITY P200 & P200E metal mount reader
Technical Support
Documentation on all Paxton products can be found on our website - http://www.paxton.co.uk/
01273 811011
Technical help is available: Monday - Friday from 07:00 - 19:00 (GMT)
Saturday from 09:00 - 13:00 (GMT)
