Paxton Swipe card 25 kit User Manual
Paxton, Technical support
14/11/2011
Ins-30048 - Swipe card 25 kit
Fitting the kit
Suitability
Mounted on metal surface
Wet environments
Security-sensitive doors
Readers mounted together
Technical Support
Technical help is available: Monday - Friday from 07:00 - 19:00 (GMT)
Saturday from 09:00 - 13:00 (GMT)
01273 811011
Documentation on all Paxton products can be found on our website - http://www.paxton.co.uk/
Exit button
(push to make)
Electric release
12V DC power
supply
12V DC release current rating must be less than 1A.
0V
0V
0V
+12V
+12V
Exit
User cards are NOT supplied with this unit. Please supply your own user cards.
This reader is compatible with any Track 2 ABA magstripe card, such as a debit/credit card.
