Software configuration
• Run the Net2 software.
• Check that the ACU has been detected by looking in the Doors screen. The firmware in the ACU's will be
automatically updated to the same revision as the PC. Do not make any changes to the software during this phase.
• Once this has finished, each ACU must be configured (as below)
Reader 1: Settings for Reader 1 and Keypad 1 on the ACU.
Reader 2: Settings for Reader 2 and Keypad 2 on the ACU.
Alarm: Contains settings for the different types of alarm.
Codes: Valid codes can be viewed, added and removed.
(Can only be viewed when a keypad is active).
Events: Shows the events for the control unit selected.
Door name: Name the ACU.
Door open time: Set the door open time.
Unlock the Door during: Permanently unlocks the door while
this timezone is active. - Should be set to 'At No Time' for
normal user operation.
Name: Each reader can be named individually if required.
Reader type: Set the reader type, if applicable.
Keypad type: Set the keypad type, if applicable.
Token data format: Select the data type being used on the
system. (New formats can be created).
Reader operating mode: Set the operating mode.
Timed operating modes: A different operating mode can be
configured within a time window.
Reader action: Set the action required when access is granted.
