Pavement Ends 44527 Flip Top - Manual (Page 2)

44527 pg 2 Rev. H 1210
Parts List and Hardware Identifi cation
Windshield Bracket - Right,
Qty - 1, Part Number 380.96 Windshield Bracket - Left,
Qty - 1, Part Number 380.97
Top Fabric Qty - 1
Quarter Window, Rt. Qty - 1
Quarter Window, Lt. Qty - 1
Rear Window Qty - 1
Windshield Header Trim Qty - 1
Tailgate Retainer Mount, Right,
Qty - 1, Part Number 311.86
Windshield Header, Qty - 1,
Part Number 381.31
Tailgate Retainer Mount, Left,
Qty - 1, Part Number 311.85
Tailgate Bar, Qty - 1,
Part Number 288.75
5/16" Black Washer, Qty - 6,
Part Number 233.04
5/16-18 Tapping Plate, Qty - 6,
Part Number 200.50
Lock Nut, Qty - 2, Part
Number 316.94
5/16-18 x 1" Phillips Bolt, Qty - 6,
Part Number 236.20
#10-15/16 Bolt, Qty - 2,
Part Number 326.85
#8 x 1/2" Pan Head Washer Screw - Black,
Qty - 4, Part Number 200.48
Bow Assembly - Right, Qty - 1,
Part Number 381.36
Bow Assembly - Left, Qty - 1,
Part Number 381.37
Side Belt Rail - Right, Qty - 1,
Part Number 381.32
Side Belt Rail - Left, Qty - 1,
Part Number 381.33
Vertical Rod, Qty - 2,
Part Number 134.50
