44527 pg 12 Rev. H 1210
Adjusting the Top
WARNING When operating the vehicle without the Quarter Windows,
the Rear Curtain should be rolled up for proper ventilation.
Quarter Windows
To remove the Quarter Windows.
Unzip the rear and top zippers.
Release the plastic strip from the
retainer. Release the Hook and
Loop Fasteners from around the
Vertical Retainer.
Removal of Soft Top for Open Air Driving
When operating the vehicle with the fabric top removed, it is very important that
the supporting hardware system be disconnected from the windshield bracket and
folded fl at to the rear of the vehicle. Wrap the elastic straps around the bows and
insert the plastic strip into the Side Belt Rail. Never operate the vehicle with the
fabric removed and the hardware in the fully erected position.
Quarter
Window
Opening the Sun Roof
Release the Windshield Header Latches and fold the Windshield
Retainer back so that it rests on the center bow and the sport bar.
