Oyen Digital DATATALE RS-M2QJ 2-BAY RAID - Manual (Page 47)

47
APPENDIX: SPECIFICATIONS
Model Name RS-M2QJ
Connector eSATA x 1, USB 2.0 x 1, 1394a x 1, 1394b x 2
Disk Support
3.5” SATA hard disk*
*Identical hard disk recommended – same
manufacturer, capacity and RPM
RAID Level
RAID 0 (Striping), RAID 1 (Mirroring), SPAN
(Large), JBOD (None RAID)
Data Transfer Speed
eSATA: up to 3Gbit/sec
USB 2.0: up to 480Mbit/sec
1394a: up to 400Mbit/sec
1394b: up to 800Mbit/sec
System Material Aluminum case with plastic parts
LED Indicators
Power / Connection / Health / Access / Rebuild /
Fan error
Power Supply
Input: AC 100-240V
Output: DC +12V/3.5A
FAN
Dimension: 80 x 80 x 10 mm (1)
Speed: 1900 R.P.M +-10%
Noise: 17.13 dB(A) max
Dimension 126 (L) x 138 (W) x 213 (H) mm
Weight (without disk) 1.35 KGS
Certification CE, FCC
