DCA-150SSKII — PARTS AND OPERATION MANUAL— REV. #1 (05/08/01) — PAGE 75
DCA-150SSKII — BATTERY ASSY.
BATTERY ASSY.
NO. PART NO. PART NAME QTY. REMARKS
1 0168511551 BATTERY ....................................... 2 ...... 115F51
2 0805000804 BATTERY SHEET 2
3 0805000904 BATTERY BAND 2
4 0805002904 BATTERY BOLT 4
5 0037808000 WING NUT 4
6 0040008000 LOCK WASHER 4
7 0041208000 PLAIN WASHER ............................. 4 ...... REPLACES 0041208000
8 0602220203 BATTERY SENSOR 1
9 C0347500004 BATTERY CABLE 1
10 8302265304 BATTERY CABLE 1
11 8302265504 BATTERY CABLE 1
12 C0347200104 EARTH CABLE 1
13 012010030 HEX HEAD BOLT ........................... 4 ...... REPLACES 0010010030
14 020310080 HEX NUT ........................................ 4 ...... REPLACES 0030010000
15 012212025 HEX HEAD BOLT ........................... 1 ...... REPLACES 0010012025
0040012000 LOCK WASHER 1
031112230 PLAIN WASHER ............................. 1 ...... REPLACES 0041212000
16 0040512000 TOOTHED WASHER 1
17 0845040414 TERMINAL CAP + 2
18 0845041304 TERMINAL CAP - 2
