DCA-150SSKII — PARTS AND OPERATION MANUAL— REV. #1 (05/08/01) — PAGE 65
DCA-150SSKII— CONTROL BOX ASSY.
31 C0224001403 CONTROL PANEL 1
32 0605011211 PIN 2
33 0601800487 FREQUENCY METER ............................... 1 ............ TRC- 65CF 220V 45 ~65HZ
34 0601808901 AC AMMETER ........................................... 1 ............ TRS- 65C0 ~300A0 ~600A
35 0601801040 CHANGE.-OVER SWITCH., AMMETER .... 1 ............ SL- 2AS
36 0601800298 AC VOLTMETER ........................................ 1 ............ TRR - 65C0 ~600V
37 0601801041 CHANGE.- OVER SWITCH., VOLTMETER.1 ............ SL - 2VS
38 0601810072 PILOT LAMP .............................................. 1 ............ LP - 132DC 220V
0601810261 BULB .......................................................... 1 ............ CT - 13W
39 0601840073 RHEOSTAT (VOLTAGE REGULATOR) ........ 1 ............ RA20A2SE102BJ 2W 1K OHM
40 0601840121 KNOB 1
41 0601810161 PANEL LIGHT ............................................. 1 ............ V325070
0601810214 BULB 1
42 0030004000 HEX NUT .................................................... 2 ............ REPLACES 0207004000
43 0601830710 SWITCH, PANEL LIGHT 1
44 C9221100004 HEX HEAD BOLT 2
0040008000 LOCK WASHER 2
031108160 PLAIN WASHER ......................................... 2 ............ REPLACES 0041208000
0080100007 SNAP RING 2
45 3871824004 STOPPER, CONTROL PANEL 1
46 952404470 PLAIN WASHER ......................................... 1 ............ REPLACES 0041206000
47 505015300 SNAP PIN .................................................. 1 ............ REPLACES 0605010502
48 C0214500104 COVER, CONTROL BOX 1
49 011008020 HEX HEAD BOLT ....................................... 8 ............ REPLACES 0017108020
50 8361827504 PANEL, CONTROL BOX 1
51 011008020 HEX HEAD BOLT ....................................... 8 ............ REPLACES 0017108020
52 011008020 HEX HEAD BOLT ....................................... 4 ............ REPLACES 0017108020
CONTROL BOX ASSY. (CONT.)
NO. PART NO. PART NAME QTY. REMARKS
