DCA-150SSKII — PARTS AND OPERATION MANUAL— REV. #1 (05/08/01) — PAGE 69
DCA-150SSKII— ENGINE & RADIATOR ASSY.
ENGINE & RADIATOR ASSY. (CONT)
NO. PART NO. PART NAME QTY. REMARKS
31 0605515074 HOSE BAND 2
32 08020810030 RESERVE TANK ........................... 1 ........ REPLACES 0802081003
33 0802010900 CAP, RESERVE TANK .................. 1 ........ REPLACES 0602010900
34 8302082103 BRACKET, RESERVE TANK 1
35 0021108020 MACHINE SCREW 2
36 020108060 HEX NUT ....................................... 2 ........ REPLACES 0207008000
37 0199601200 HOSE 1
38 0193601200 HOSE 1
39 0605515013 HOSE BAND 3
40 0193600450 HOSE 1
41 0193600800 HOSE 1
42 0268200900 HOSE 1
43 0605515132 HOSE BAND 2
44 8302256104 CLAMPER ROD 1
45 8152256104 CLAMPER ROD 1
46 012210020 HEX HEAD BOLT ........................... 3 ...... REPLACES 0017110020
