DCA-150SSKII — PARTS AND OPERATION MANUAL— REV. #1 (05/08/01) — PAGE 71
DCA-150SSKII — ENGINE OPERATING PANEL ASSY.
ENGINE OPERATING PANEL ASSY.
NO. PART NO. PART NAME QTY. REMARKS
1 C0352100803 OPERATING PANEL 1
2 0017106016 HEX HEAD BOLT 4
3 0207006000 HEX NUT 1
4 0602120558 METER PANEL ASS’Y ................... 1 ...... 1573708760; INCLUDE ITEM W/*
0602120701 WIRING HARNESS 1
4-1* 0602129032 METER PANEL .............................. 1 ...... 0577764130
4-2* 0602120069 TACHOMETER ............................... 1 ...... 1005694600
4-3* 0602122037 OIL PRESSURE GAUGE ............... 1 ...... 1005760430
4-4* 0602123087 WATER TEMP. GAUGE .................. 1 ...... 1005752740
4-5* 0602121060 CHARGING AMMETER ................. 1 ...... 1005730330
4-6* 0602115031 INDICATOR ASS’Y ......................... 1 ...... 0559004040
4-7* 0602129031 MACHINE SCREW 2
5 0021806020 MACHINE SCREW 2
6 0021806050 MACHINE SCREW 2
7 0602120129 CABLE, TACHOMETER ................. 1 ...... 0578909990
8 0602122251 UNIT, OIL PRESSURE ................... 1 ...... 0716000760
9 0602123250 UNIT, WATER TEMPERATURE ...... 1 ...... 0715000331
10 8132142004 SLIDE LEVER 1
11 0601840190 KNOB ............................................. 1 ...... REPLACES 0805012904
12 0036003000 HEX NUT 1
13 7452140504 BRACKET 1
14 0030008000 HEX NUT 2
15 0605010503 SNAP PIN 1
16 6008155390 STARTER SWITCH ........................ 1 ...... REPLACES 0602100049
INCLUDE ITEM W/#
16-1# 0000000615 KEY, STARTER SWITCH
17 6008152371 PREHEATLAMP ............................. 1 ...... REPLACES 0602102047
18 C0355300114 GOVERNOR ROD 1
19 0602180106 BALL JOINT 2
20 0030004000 HEX NUT 2
21 0207006000 HEX NUT 2
22 952404470 PLAIN WASHER ............................. 2 ...... REPLACES 0041206000
23 C0355200204 ROD GUIDE 1
24 0017112025 HEX HEAD BOLT 2
25 C0484000303 SUPPORT LEG 1
26 0017110025 HEX HEAD BOLT 4
0207010000 HEX NUT 4
