DCA-150SSKII — PARTS AND OPERATION MANUAL— REV. #1 (05/08/01) — PAGE 67
DCA-150SSKII— ENGINE & RADIATOR ASSY.
ENGINE & RADIATOR ASSY.
NO.
PART NO.
PART NAME
QTY.
REMARKS
1
C0924200084
ENGINE .......................................... 1 ...... KOMATSU S6D 108E - 2
INCLUDE ITEMS W/*
1-1*
6001816740
ELEMENT, AIR CLEANER ............. 1 ....... REPLACES 0602046338
1-2*
6136515121
CARTRIDGE, OIL FILTER ............. 1 ....... REPLACES 0602041147
1-3*
6003118293
CARTRIDGE, FUEL FILTER .......... 1 ....... REPLACES 0602042146
1-4*
6004111191
CARTRIDGE., CORROSION
RESISTOR ..................................... 1 ....... REPLACES 0602045141
1-5*
0602040678
DUST SENSOR .............................. 1 ....... REX01 - 8126
2
6151619350
RADIATOR ...................................... 1 ....... REPLACES 0602011866
3
6151619340
RUBBER SHEET ............................ 2 ....... REPLACES 0605000073
4
00100120605
HEX HEAD BOLT
4
5
0030012000
HEX NUT
8
6
031112230
PLAIN WASHER ............................. 8 ....... REPLACES 0041212000
7
C0311100004
BRACKET, RADIATOR
2
8
0017110025
HEX HEAD BOLT
6
9
6221619320
RADIATOR HOSE ........................... 1 ....... REPLACES 0602014543
10
6221619330
RADIATOR HOSE ........................... 1 ....... REPLACES 0602014425
11
0726020971
RADIATOR HOSE ........................... 1 ....... REPLACES 0602014544
12
0728100909
HOSE BAND .................................. 1 ....... REPLACES 0602014056
13
0728100809
HOSE BAND .................................. 2 ....... REPLACES 0602014067
14
0728101029
HOSE BAND .................................. 1 ....... REPLACES 0602014350
15
0728100197
HOSE BAND .................................. 2 ....... REPLACES 0602014058
16
0605000060
RUBBER SUSPENSION
2
17
0030012000
HEX NUT
4
18
0040012000
LOCK WASHER
4
19
C9101000104
DRAIN JOINT
1
20
0802024004
PACKING, OIL PAN SIDE
1
21
0805008004
PACKING
1
22
0802025104
JOINT BOLT
1
23
C0321200004
DRAIN JOINT
1
24
C0321300004
DRAIN PLUG
1
25
011208025
HEX HEAD BOLT .......................... 2 ........ REPLACES 0017108025
26
0130008000
ELBOW JOINT, 3/4
1
27
0134308100
LONG NIPPLE
1
28
0603325017
VALVE ............................................1 ........ BBS22020
29
0602022294
HOSE JOINT
1
30
0265800850
DRAIN HOSE
1
