DCA-150SSKII — PARTS AND OPERATION MANUAL— REV. #1 (05/08/01) — PAGE 51
DCA-150SSKII — GENERATOR SHUT-DOWN PROCEDURE
Figure 65. Off/Manual Auto Switch (OFF)
Engine Shutdown
To shut-down the generator use the following procedure:
1. Place both the MAIN, GFCI and LOAD circuit breakers
to the "OFF position"
2. Turn the Engine Throttle Handle (Figure 63)to the left and
push in to set the speed to 'low'.
Figure 63. Engine Throttle Lever (low)
Figure 66. MPEC Engine Running
Status LED (OFF)
6. Verify that the "Engine Running" status LED (Figure
66) on the Microprocessor Engine Control Module
(MPEC) display is "OFF" (not lit).
7. If the generator is equipped with an ignition switch, (Figure
67) turn the key to the left to the "OFF" positionturn off
the engine.
5. Place the Off/Manual/Auto Switch (Figure 65) in the "OFF/
RESET" position.
4. Let the engine cool by running it for 3-5 minutes with no
load applied.
3. If the generator is equipped with an idle control switch, set
the switch to "OFF" positon. (Figure 64)
Figure 64. Idle Control Switch (OFF)
Figure 67. Off/Manual Auto Switch (OFF)
8. Remove the load from the UNVO terminal strip (Figure 14 -
page 33).
