dca45SSIU4F 60 hz generator• operatIon manUal — rev. #0 (09/09/14) — page 95
NaMepLate aND DeCaLs assy.
no.
part no.
part name
QtY.
remarKS
1
M1551000303
DECAL: ENGINE OPERATING ................................................ 1 ........... M15100030
2
M9520000104
DECAL: AMMETER CHANGE-OVER SW. .............................. 1 ........... M92000010
3
M9520000204
DECAL: VOLTMETER CHANGE-OVER SW. ........................... 1 ........... M92000020
4
M1551000203
DECAL: GENERATOR CONTROL .......................................... 1 ........... M15100020
5
M9520100704
DECAL: WARNING ARC FLASH ............................................. 1 ........... M92010070
6
M9520100304
DECAL: GENERAL CAUTIONS .............................................. 1 ........... M92010030
7
M9520100004
DECAL: WARNING ELECTRICAL SHOCK ............................. 2 ........... M92010000
8
M9520200404
DECAL: O.C.R. RESET ........................................................... 1 ........... M92020040
9
M9520200003
DECAL: CONNECTION OF OUTPUT CABLE ........................ 1 ........... M92020000
10
M9520000004
DECAL: GROUNDING ............................................................. 2 ........... M92000000
11
M9520100404
DECAL: DANGER HIGH VOLTAGE ......................................... 1 ........... M92010040
12
M9520100204
DECAL: CAUTION CHANGE-OVER SW. ................................ 1 ........... M92010020A
13
M9500300104
DECAL: + ................................................................................. 1 ........... M90030010
14
M9500300004
DECAL: - .................................................................................. 1 ........... M90030000
15
M9503100004
DECAL: WARNING RADIATOR CAP ...................................... 1 ........... M90310000
16
M9500100004
DECAL: WATER ....................................................................... 1 ........... M90010000
17
M9510100004
DECAL: CAUTION HIGH TEMP. .............................................. 1 ........... M91010000
18
M9503200004
DECAL: WARNING EXHAUST GAS ....................................... 1 ........... M90320000
19
M9503000004
DECAL: WARNING ROTATING PART ..................................... 2 ........... M90300000
20
M1561101103
STRIPE
1
21
M1561101203
STRIPE
2
22
M1561101303
STRIPE
1
23
M1561101403
STRIPE
1
24
M1561101504
STRIPE
2
25
M1561101603
STRIPE
1
26
M1561101703
STRIPE
1
27
M9520100603
DECAL: WARNING AUTO START ........................................... 2 ........... M92010060
28
M1551000504
DECAL: NOTICE LOAD SHARING ......................................... 1 ........... M15100050
29
M9503000103
DECAL: DAILY CHECK WATER AND OIL ............................... 1 ........... M90300010
30
M9520000504
DECAL: START CONTACT ...................................................... 1 ........... M92000050
31
M9520100503
DECAL: WARNING .................................................................. 1 ........... M92010050
32
M9511100104
DECAL: NOTICE RECEPTACLE ............................................. 1 ........... M91110010
33
M1550002203
DECAL: AUXILIARY OUTPUTS .............................................. 1 ........... M15000220
34
M9510100403
DECAL: WARNING BATTERY CONNECT .............................. 1 ........... M91010040
35
M9501500004
DECAL: DIESEL FUEL ............................................................ 1 ........... M90150000
36
M9500000004
DECAL: OIL DRAIN ................................................................. 1 ........... M90000000
37
M9510000104
DECAL: DOCUMENT BOX LOCATED .................................... 1 ........... M91000010
38
M9511100004
DECAL: ENVIRONMENTAL WARNING .................................. 1 ........... M91110000
39
M9503200104
DECAL: DANGER EX. GAS (INDOOR) ................................... 1 ........... M90320010
40
M920214100
DECAL: WARNING START FIRES .......................................... 1 ........... M90420000
41
M2550002303
OPERATING PRECAUTIONS .................................................. 1 ........... M25000230
42
M9510000004
DECAL: FLUID DRAIN ............................................................. 1 ........... M91000000
43
M1550001504
CAUTION: LIFTING CAPACITY ............................................... 1 ........... M15000150
44
M9500100304
INTER-COOLER DRAIN ......................................................... 1 ........... M90010030
45
M9510200002
STICKER, MQ ......................................................................... 1 ........... M91020000
46
0600500092
EMBLEM
1
47
0021106015
MACHINE SCREW
4
48
M9511200103
TIER 4F ................................................................................... 1 ........... M91120010
