dca45SSIU4F 60 hz generator• operatIon manUal — rev. #0 (09/09/14) — page 17
GeNeratOr MajOr COMpONeNts
PRESS TO LOCK
3 PHASE 480/277 1 PHASE 240/120
4
11 12
2
6 7 8
1
U V W O
3
OFF
U-V W-U
V-W
OFF
V
W U
INCREASE DECREASE PSI
OIL PRESS
0 25 50 75 100 °F
WATER TEMP 100
140 180 220
260 VOLTS
BATTERY 6
12 18 24
30
°F
FUEL E
½
F RPMX10
SPEED 0
120 150 180
210 60 Low Oil Pressure
High Temp.
Over Crank
Over Speed
Engine Started
ECU ® Intergrated Gauge Control
45
9 5
10
table 4. generator major components
Item no. dEScRIPTION
1 Muffler Assembly
2 Voltage Selector Switch Assembly
3 Generator Assembly
4 Output Terminal Assembly
5 Circuit Breaker Assembly
6 Battery Assembly
7 Engine Assembly
8 Fuel Tank Assembly
9 Enclosure Assembly
10 Main Circuit Breaker
11 Generator Control Panel Assembly
12 Gauge Unit Assembly Figure 3. GeneratorMajor Components
