page 12 — dca45SSIU4F 60 hz generator • operatIon and partS manUal — rev. #0 (09/09/14)
GeNeratOr/eNGiNe speCiFiCatiONs
table 1. Generator Specifications
model DCA45SSIU4F
Type
Revolving field, self ventilated,
open protected type synchronous generator
armature connection Star with Neutral Zigzag
Phase 3Ш 3Ш
Standby Output 40 KW (50 KVA) 28.8 KW
Prime Output 36 KW (45 KVA) 26 kW
3Ø voltage (l-l/l-n)
voltage Selector Switch at 3Ø 240/139
208Y/120, 220Y/127, 240Y/139 N/A
3Ø voltage (l-l/l-n)
voltage Selector Switch at 3Ø 480/277
416Y/240, 440Y/254, 480Y/277 N/A
1Ø voltage (l-l/l-n)
voltage Selector Switch at 1Ø 240/120
N/A 240/120
Power Factor 0.8 1.0
Frequency 60 Hz
Speed 1800 rpm
aux. ac power Single Phase, 60 Hz
aux. voltage/output 4.8 Kw (2.4 kW x 2)
dry Weight 2,337 lbs. (1,060 kg)
Wet Weight 2,976 lbs. (1,350 kg)
table 2. Engine Specifications
model Isuzu 4LE2X Tier 4 Final
Type
Water-cooled, direct injection, turbo-charged
air cooled EGR
no. of cylinders 4 cylinders
Bore x Stroke 3.35 in. x 3.78 in. (85 mm x 96 mm)
displacement 133 cu. in. (2.17 liter)
Rated Output 59 HP at 1800 rpm
Starting Electric
coolant capacity (radiator) 4.44 gallons (16.8 liters) 1
lube oil capacity 3.2 gallons (12.2 liters) 2
lubricating type oil API service class CJ-4 SAE 15W-40
Fuel Type #2 Diesel Fuel (Ultra low sulfur diesel fuel only)
Fuel leak Warning capacity 21.1 gal. (80 liters)
Fuel Tank capacity 79.2 gallons (300 liters)
Fuel consumption
2.93 gal. (11.1 L)/hr at full load 2.20 gal. (8.31 L)/hr at 3/4 load
1.60 gal. (6.04 L)/hr at 1/2 load 1.04 gal. (3.92 L)/hr at 1/4 load
Battery 27 (CCA 0°F 525A) X 1
1 Includes engine and radiator hoses
2 Includes filters
