DCA-100SSJU — PARTS AND OPERATION MANUAL (STD)— REV. #2 (05/03/01) — PAGE 85
31 M3453200112 SPLASHER PANEL ......................... 1 ......... REPLACES M3453200102
S/N7400001 TO 7400026
M3453200112 SPLASHER PANEL ......................... 1 ......... S/N7400027 TO 7400205
M3453200122 SPLASHER PANEL ......................... 1 ......... S/N7400206 TO 7400295
M3453200132 SPLASHER PANEL ......................... 1 ......... S/N7400296~
32 011208060 HEX. HEAD BOLT ............................ 4 ......... REPLACES 0016908055
33 012210025 HEX. HEAD BOLT ............................ 2 ......... REPLACES 0016910025
34 M3453000703 SIDE DOOR 1
M3493400704 ACOUSTIC SHEET 1
35 M3453000603 SIDE DOOR 1
M3493400804 ACOUSTIC SHEET 1
36 M3453000503 SIDE DOOR 1
M3493401004 ACOUSTIC SHEET 1
37 M3453000403 SIDE DOOR 1
M3493401104 ACOUSTIC SHEET 1
38 M3453300303 DUCT 1
M3493400904 ACOUSTIC SHEET 1
39 M3453300503 DUCT 1
M3493401404 ACOUSTIC SHEET 1
40 M3453300203 DUCT 1
M3493401204 ACOUSTIC SHEET 1
41 0207006000 HEX. NUT 25
42 89114000002 DOOR HANDLE ASSY. .................... 4 ......... REPLACES M9113000002
43 0027106016 MACHINE SCREW ......................... 16 ......... REPLACES 0021806015
020106050 HEX. NUT ....................................... 16 ......... REPLACES 0030006000
44 M9110100204 HINGE 4
45 M9110100304 HINGE 4
46 M9116100004 WASHER 8
47 011008020 HEX. HEAD BOLT ............................ 9 ......... REPLACES 0016908020
48 0601850097 DOOR STOPPER 8
49 0027208025 MACHINE SCREW 8
50 0845031504 BLIND PLUG .................................... 8 ......... REPLACES M9310000004
51 M3453700004 DOOR BRACKET 1
52 011106015 HEX. HEAD BOLT ............................ 4 ......... REPLACES 0016906015
53 011008020 HEX. HEAD BOLT ............................ 1 ......... REPLACES 0016908020
0040508000 TOOTHED WASHER 1
ENCLOSURE ASSY.
DCA-100SSJU --- ENCLOSURE ASSY.
NO. PART NO. ITEM QTY. REMARKS
ADD THE FOLLOWING DIGITS AFTER THE PART NUMBER
WHEN ORDERING ANY PAINTED PANEL TO INDICATE
COLOR OF UNIT:
1-ORANGE
2-WHITE
3 -SPECTRUM GRAY
4 -SUNBELT GREEN
5 -BLACK
6 -CATERPILLAR YELLOW
7 -CATO GOLD
8 -RED
THE SERIAL NUMBER MAY BE REQUIRED.
