DCA-100SSJU — PARTS AND OPERATION MANUAL (STD)— REV. #2 (05/03/01) — PAGE 67
27
M3223000203
CONTROL PANEL
1
28
0601807630
FREQUENCY METER ................................. 1 ......... 264250 DJDJ9
29
0601808953
AC AMMETER ............................................. 1 ......... 260240LSLS1JCA
30
0601801040
CHANGE-OVER SWITCH, AMMETER ....... 1 ......... SL-2AS
31
0601806813
AC VOLTMETER .......................................... 1 ......... 260244SJSJ1
32
0601801041
CHANGE-OVER SWITCH, VOLTMETER .... 1 ......... SL-2VS
33
0601840073
RHEOSTAT (VOLTAGE REGULATOR) ......... 1 ......... RA20A2SE102BJ 2W 1K OHM
34
0601840121
KNOB .......................................................... 1 ......... 25N
35
M1223100004
STOPPER
1
36
0027105015
MACHINE SCREW
2
37
0027105015
MACHINE SCREW
4
38
M9220100004
SET SCREW
1
39
0080200007
SNAP RING
1
40
0601821370
RECTIFIER .................................................. 1 ......... DE 4503 REPLACES 0601823240
41
0027104020
MACHINE SCREW ...................................... 1 ......... S/N7400001 TO 7400205
AND 7400296~
0027105020
MACHINE SCREW ...................................... 1 ......... S/N7400206 TO 7400295
42
0602200478
EMERGENCY RELAY ................................. 1 ......... 10701-60602,3
S/N7400001 TO 7400295
43
0027105040
MACHINE SCREW ...................................... 2 ......... S/N7400001 TO 7400295
44
0602202592
STARTER RELAY ........................................ 1 ......... AT141011
45
011808015
MACHINE SCREW ...................................... 2 ......... REPLACE 0027106015
46
0601821370
RECTIFIER .................................................. 1 ......... DE 4503 REPLACES
0601823240 S/N7400296~
47
DYN10794000012 CONTROLLER ............................................. 1 ......... REPLACES 0602202599 S/N7400296~
MPS6724
SPEED SENSOR ........................................ 1 ......... REPLACES 0602120485 S/N7400296~
48
0027105015
MACHINE SCREW ...................................... 4 ......... S/N7400296~
49
LY2US12VDC
RELAY ......................................................... 1 ......... REPLACES 0601823768
S/N7400296 TO 7400310
0601827656
RELAY ......................................................... 1 ......... LY2-D 12VD S/N7400311~
0601823109
BASE ........................................................... 1 ......... PTS 08A-E S/N 7400296~
PYCA1
CLIP ............................................................. 2 ......... REPLACES 0601824400S/N7400296~
50
0601823223
RECTIFIER .................................................. 1 ......... 30D4 S/N7400296 TO 7400310
51
0027104020
MACHINE SCREW ...................................... 2 ......... S/N7400296~
NO.
PART NO.
ITEM
QTY.
REMARKS
DCA-100SSJU --- CONTROL BOX ASSY.
CONTROL BOX ASSY.
