DCA-100SSJU — PARTS AND OPERATION MANUAL (STD)— REV. #2 (05/03/01) — PAGE 63
1 C0110000220 ROTOR ASSY. 1
1-1 FIELD ASSY 1
1-2 8101070033 FAN 1
1-3 8101611014 COUPLING DISK 5
1-4 8101015003 BALANCING PLATE 1
1-5 0012110030 HEX. HEAD BOLT 8
1-6 0042510000 LOCK WASHER 8
1-7 8101026013 SET PLATE, RECTIFIER 1
1-8 0601821349 RECTIFIER .......................................... 2 ............PT 3610
1-9 0601822601 SURGE ABSORBER ........................... 1 ............ERZ-M14JK21A
1-10 8001020004 INSULATOR WASHER 1
1-11 8001020504 INSULATOR WASHER 1
1-12 0010110020 HEX. HEAD BOLT 4
1-13 0040010000 LOCK WASHER 4
1-14 0601000209 BALANCING WEIGHT KIT 1
1-15 0071906311 BEARING ............................................. 1 ............6311DDU C3
2 C0130000103 STRATOR ASSY 1 S/N7400001 TO 7400356
C0130200003 STRATOR ASSY. 1 S/N7400357~
3 0845041804 GROMMET 2
4 8101315202 END BRACKET 1
5 8101350013 FIELD ASSY EXCITER 1
6 0012110070 HEX. HEAD BOLT ................................ 4 ............S=26
7 0042610000 LOCK WASHER 4
8 0041210000 PLAIN WASHER 4
9 0010110035 HEX. HEAD BOLT 6
10 0040010000 LOCK WASHER 6
11 0041210000 PLAIN WASHER 6
12 8101310014 COVER, BEARING 1
13 8131312014 GASKET, BEARING 1
14 8131331003 COVER, END BRACKET 1
15 0017106012 HEX. HEAD BOLT 10
16 8101333003 COVER, END BRACKET 1
17 0010106030 HEX. HEAD BOLT 2
18 0040006000 LOCK WASHER 2
19 0041206000 PLAIN WASHER 2
20 8101614003A COUPLING RING ................................ 1 ............REPLACES M2163400003
21 0013904044 HEX. HEAD BOLT ................................ 8 ............S/N7400001 TO 74001060
034320415 HEX. HEAD BOLT ................................ 8 ............SN 7400161~
22 0043604000 LOCK WASHER 8
23 0070506306 BEARING ............................................. 1 ............6303ZZ
24 0012810030 HEX. HEAD BOLT 8
25 0010310035 HEX. HEAD BOLT .............................. 12 ............S/N7400001 TO 7400160
0012810030 HEX. HEAD BOLT .............................. 12 ............7400161~
26 0042510000 LOCK WASHER ................................. 12 ............S/N7400001 TO 7400160
27 8111332014 COVER, FAN 1
28 0605000063 RUBBER SUSPENSION ...................... 2 ............KA-120SS
29 0030016000 HEX. NUT 2
0040016000 LOCK WASHER 2
30 0600815000 NUT 1
NO. PART NO. ITEM QTY. REMARKS
DCA-100SSJU --- GENERATOR ASSY.
GENERATOR ASSY.
