DCA-100SSJU — PARTS AND OPERATION MANUAL (STD)— REV. #2 (05/03/01) — PAGE 83
NO. PART NO. ITEM QTY. REMARKS
1 M3413000202 BASE ............................................... 1 ......... S/7400001 TO 7400205
M3413000212 BASE ............................................... 1 ......... S/N7400206 TO 7400295
M3413000222 BASE ............................................... 1 ......... S/N7400296~
2 M1413400004 UNDER COVER 1
3 011008020 HEX. HEAD BOLT ............................ 2 ......... REPLACES 0016908020
4 M3423000302 FRONT FRAME ............................... 1 ......... S/N7400001 TO 7400205
M3423000602 FRONT FRAME ............................... 1 ......... S/N7400206~
M3493100203 ACOUSTIC SHEET ......................... 1 ......... S/N7400001 TO 7400205
M3493100503 ACOUTSTIC SHEET ....................... 1 ......... S/N7400206~
5 012210025 HEX. HEAD BOLT ............................ 6 ......... REPLACES 0016910025
6 M3493100304 ACOUSTIC SHEET 1
7 011008020 HEX. HEAD BOLT ........................... 14 ......... REPLACES 0016908020
8 M3433000102 CENTER FRAME 1
M3493200004 ACOUSTIC SHEET 1
9 0010114040 HEX. HEAD BOLT 12
020114110 HEX. NUT ....................................... 12 ......... REPLACES 0030014000
030214350 LOCK WASHER .............................. 24 ......... REPLACES 0040014000
031114260 PLAIN WASHER ............................. 24 ......... REPLACES 0041214000
10 M3443000202 REAR FRAME ................................. 1 ......... S/N7400001 TO 7400295
M3443000212 REAR FRAME ................................. 1 ......... S/N7400296~
11 012210025 HEX. HEAD BOLT ............................ 4 ......... REPLACES 0016910025
12 M3443300203 REAR COVER 1
13 M3443300303 DUCT, REAR COVER 1
M3493300303 ACOUSTIC SHEET 1
14 0207006000 HEX. NUT 12
15 011008020 HEX. HEAD BOLT ........................... 10 ......... REPLACES 0016908020
16 M3443200103 REAR DOOR .................................... 1 ......... S/N7400001 TO 7400099
M3443200113 REAR DOOR .................................... 1 ......... S/N7400100~
17 M3443600104 WINDOW PLATE 1
18 020106050 HEX. NUT ....................................... 10 ......... REPLACES 0037906000 AND 0207306000
952404470 PLAIN WASHER ............................. 20 ......... REPLACES 0041206000 AND 0041206000
19 89114000002 DOOR HANDLE ASSY. .................... 1 ......... REPLACES M9113000002
20 0027106016 MACHINE SCREW .......................... 4 ......... REPLACES 0021806015
020106050 HEX. NUT ........................................ 4 ......... REPLACES 0030006000
21 M9110100204 HINGE 2
22 M9116100004 WASHER 2
23 011008020 HEX. HEAD BOLT ............................ 3 ......... REPLACES 0016908020
24 0845031504 BLIND PLUG .................................... 2 ......... REPLACES M9310000004
25 M3463100203 ROOF PANEL 1
M3493500203 ACOUSTIC SHEET 1
26 M3463200102 ROOF PANEL 1
M3493500303 ACOUSTIC SHEET 1
27 M3463500104 OVER COVER, FRONT FRAME 1
28 011008020 HEX. HEAD BOLT ........................... 37 ......... REPLACES 0016908020
29 1625165103 BONNET CAP .................................. 1 ......... REPLACES M9310000103
30 1625165204 CHAIN ASSY. .................................. 1 ......... REPLACES M1483600204
ENCLOSURE ASSY.
DCA-100SSJU --- ENCLOSURE ASSY.
