DCA-100SSJU — PARTS AND OPERATION MANUAL(STD)— REV. #2 (05/03/01) — PAGE 69
1 M3923200014 ENGINE .......................................... 1 ........... JOHN DEERE 6068TF S/N7400001 TO 7400356
M3925200004 ENGINE .......................................... 1 ........... JOHN DEERE 6068TF150 S/N7400357~
0602011491 FAN BELT 1
1-1 0602041290 ELEMENT, OIL FILTER ................. 1 ........... JOHN DEERE RE59754A
1-2 0602042590 ELEMENT, FUEL FILTER .............. 1 ........... JOHN DEERE RE92418
1-3 0602014297 ELECTRIC HEATER ...................... 1 ........... JOHN DEERE RE29658 S/N 7400001 TO 7400175
ELECTRIC HEATER ASSY. ........... 1 ........... JOHN DEERE RE502668 S/N 7400176~
2 0602060010 BLOWER FAN ............................... 1 ........... 422198
3 0602061000 FAN SPACER ................................. 1 ........... JOHN DEERE R81911
4 0012110095 HEX. HEAD BOLT .......................... 4 ........... S=31
5 030210250 LOCK WASHER ............................. 4 ........... REPLACES 0042510000
6 M2303200303 ENGINE FOOT 2
7 0131151240 HEX. HEAD BOLT .......................... 6 ........... REPLACES 0010312030
8 0040012000 LOCK WASHER 6
9 0605000060 RUBBER SUSPENSION ............... 2 ........... KA-80SS
10 0030012000 HEX. NUT 2
11 0040012000 LOCK WASHER 2
12 0602011988 RADIATOR ..................................... 1 ........... JOHN DEERE RE52824
0602012723 RADIATOR ..................................... 1 ........... C2810060000 S/N 7400206~
12-1 0602011067 CAP ................................................ 1 ........... S/N7400001~7400205
0602011066 CAP ................................................ 1 ........... S/N7400206~
12-2 0199101200 HOSE ............................................. 1 ........... S/N7400206~
13 0602010795 FAN COVER ................................... 1 ........... C2810044210 S/N7400001 TO 7400205
14 0013006008 HEX. HEAD BOLT .......................... 8 ........... S/N7400001 TO 7400205
15 0043106000 PLAIN WASHER ............................ 8 ........... S/N7400001 TO 7400205
16 M3310200204 RADIATOR BRACKET .................. 1 ........... S/N7400001 TO 7400205
17 M3310200404 RADIATOR BRACKET .................. 1 ........... S/N7400001 TO 7400205
18 0013006008 HEX. HEAD BOLT .......................... 8 ........... S/N7400001 TO 7400205
19 030206150 LOCK WASHER ............................. 8 ........... REPLACES 0043006000 S/N7400001 TO 7400205
20 0043106000 PLAIN WASHER ............................ 8 ........... S/N7400001 TO 7400205
21 011008020 HEX. HEAD BOLT .......................... 8 ........... REPLACES 0016908020
22 0138102000 PLUG ............................................. 1 ........... S/N7400001 TO 7400205
23 M3310500003 RADIATOR HOSE ......................... 1 ........... S/N7400001 TO7400205
M3310500403 RADIATOR HOSE ......................... 1 ........... S/N7400206~
24 M3310500103 RADIATOR HOSE ......................... 1 ........... S/N 7400001 TO 7400205
M3310500503 RADIATOR HOSE ......................... 1 ........... S/N7400206~
25 0605515148 HOSE BAND .................................. 2 ........... 5040
26 0605515147 HOSE BAND .................................. 2 ........... 5032
27 0605512190 HOSE JOINT ................................. 1 ........... S/N7400001 TO 7400205
28 7812014003B DRAIN JOINT ................................. 1 ........... REPLACES M2320300103
S/N7400001 TO 7400205
29 M9200200004 DRAIN JOINT ................................. 1 ........... S/N7400001 TO 7400205
30 0150000018 O RING .......................................... 1 ........... A P18 S/N7400001 TO 7400205
31 011206020 HEX. HEAD BOLT .......................... 2 ........... REPLACES 0016906020 S/N7400001 TO 7400205
32 0191300580 DRAIN HOSE ................................. 1 ........... S/N7400001 TO 7400205
33 0605515189 HOSE BAND .................................. 2 ........... 91004 S/N7400001 TO 7400205
34 0602046258 AIR CLEANER ............................... 1 ........... FRG100297
0602046377 ELEMENT, AIR CLEANER ............ 1 ........... P778214
35 0602040650 INDICATOR, AIR CLEANER ......... 1 ........... RBX00-2252
36 0603306385 NIPPLE ........................................... 1 ........... S/N 7400001 TO 7400004
37 0602040596 BAND, AIR CLEANER .................... 2 ........... P00-4076
38 011008020 HEX. HEAD BOLT .......................... 4 ........... REPLACES 0016908020
DCA-100SSJU ENGINE AND RADIATOR ASSY.
